ThermalLimits.ai is a state-of-the-art tool that yields real world, high value results via Machine Learning. It enables powerful predictive capability into crucial operating limits – ensuring compliance with technical specifications, enabling reduced reload fuel costs, and eliminating operational challenges.
ThermalLimits.ai is a robust state-of-the-art SaaS application for the nuclear power industry that provides unparalleled accuracy for online thermal limit forecasting in both reload core design and cycle management engineering applications. Additional capabilities of these models include: –An average bias of less than 0.75% for the max MFLPD and MAPRAT, compared to more than a 4% mean bias for conventional offline methods.
Accurate predictions of core-wide and local behavior are crucial to assuring that targeted margins to the operating limits are maintained. Deviation between measured performance and design predictions can lead to operational challenges, such as unplanned derated conditions, premature coastdown, or increased fuel costs by loading more fuel than required for targeted energy production. Historically, inability to accurately predict online thermal limits from offline methods has challenged core design and cycle management.
While actual operations may at times depart from cycle design basis projections, there exists an inherent bias between offline and online methods that stems from the nature of the two systems. Both methodologies rely on a three-dimensional neutronics simulator model to calculate the reactor’s power, moderator, void, and flow distributions —from which margin to thermal limits can be determined. However, these calculations are approximations, and the offline quantities determined from them are inexact estimates that lead to uncertainty in thermal limits.
Online methods, on the other hand, employ an adaptive process through feedback directly from in-core nuclear instrumentation while the reactor is online. Up until recently, there has been no reliable method to bridge the gap between online and offline methods leading to inaccurate and inconsistent predictions of online thermal limits.
The predictive capability of ThermalLimits.ai is illustrated below for a typical test cycle for a large BWR. Individual models for each of the MFLCPR, MFLPD, and MAPRAT distributions demonstrate an average reduction in the observed bias by 47% (1.9x) for MFLCPR, 75% (4.0x) for MFLPD, and 72% (3.5x) for MAP , RAT.
More-over, across all fuel cycles independently tested, the maximum steady-state bias between online values and model predictions never exceeds 3.9% (for MAPRAT and MFLPD) and 1.5% for MFLCPR.
Blue Wave AI Labs is pioneering online thermal limit prediction capability with the creation of ThermalLimits.ai to address these deficiencies. Our proprietary physics-informed approach uses machine learning (ML) to leverage historical fuel cycle data, outputs from core simulators, and past online thermal performance to construct a reliable offline surrogate to enable predicting the online thermal limits for a future cycle…
The underlying methodology used to develop these models is the notion of an error-correction deep neural network that leverages the offline nodal or bundle thermal limit array in conjunction with additional offline datasets to train a network that predicts the corresponding online thermal limit nodal or bundle array, thereby enabling predictive capability for online thermal limits from offline nodal power distributions.
Typical situations require approximately three fuel cycles worth of offline and online datasets for a given reactor unit. ThermalLimits.ai is compati4ble with outputs from most vendor and vendor-independent nuclear fuel analysis software and methods.
ThermalLimits.ai is accessed via a web browser and is available for all standard computing platforms with a high-speed Internet connection, running most modern 32- and 64-bit operating systems and mobile operating systems: Linux, Windows, macOS, Android, iOS, and UNIX architectures are all acceptable environments for ThermalLimits.ai.
Energize reload design with the BWnuclear.ai software suite. These AI-based predictive algorithms integrate seamlessly, whether it be for reload core design or cycle management applications.
Get complete visibility into thermal performance with our intuitive interface. Access historical data to refine models, generate accurate thermal limit projections, and retrieve detailed reports — all from a single platform designed for operational efficiency and precision.
Inability to accurately predict online thermal limits from offline methods has challenged core design and cycle management.
Offline thermal limits calculations are approximations, and the quantities determined from them are inexact estimates that lead to uncertainty in thermal limits.
Inaccurate and inconsistent predictions of online thermal limits yield inefficent core conditions, premature coastdown, lost revenue, and/or increased fuel costs.
Or loading more fresh fuel than necessary (Direct Cost Impact)
Example demonstrating the accuracy between the offline, online, and model predictions for location of max MFLPD.
Leverage your data with Blue Wave AI Labs to boost efficiency, reduce risk, and drive smarter decisions—powered by predictive AI.
We use advanced AI and Machine Learning to turn your data into clear insights and innovative solutions for real-world challenges. Our experts help reduce risk, boost efficiency, and optimize performance.
